Figure 8. Typical section of proposed pavement
Figure 12. Placement of interlocking paving blocks.
Table 1. Comparison of the working platforms
Pasir Gudang,
Johor
Vung Tau,
Vietnam
Gebeng,
Kuantan
Subsoils
10 m soft clay
10 m soft clay
4.5 m soft clay
Working
Platform
Fabrication
Yard
Fabrication
Yard
Container
Yard
Handling
Equipment
Crawler Crane
(250T)
Crawler Crane
(track pressure
50t/m
2
)
Reach Stacker
(105T axle
load)
Pavement
Details
1m thick
quarry waste
1 m high
geocell;
2 m thick MSL
with TriAx
1 m high
geocell;
500-750 mm
thick MSL
with TriAx
Geogrids
2 layers SS2
5 layers TriAx
3 layers TriAx
Granular
Materials
Quarry Waste
75mm down
aggregates
75mm down
aggregates
CBR
2%
1%
1%-2%
Settlement
< 40 mm
< 100 mm
Recipe design
Figure 9. Laying of TriAx geogrids
REFERENCES
Chaddock, B. C. J. 1988. Deformation of road foundations with geogrid
reinforcement,
TRL Research Report 140
.
Chan, S.F. 2000. Reinforced soil structures using geogrids.
Proceedings
2nd Asian Geosynthetics Conference
, Kuala Lumpur. 1, 95-110.
Figure 10. Install diaphragm with Tensar uniaxial gegorid
Jenner, C.G., Bassett, R.H. & Bush, D.I. 1988. The use of slip line fields
to assess improvement in bearing capacity of soft ground by a
cellular foundation mattress installed at the base of an embankment.
Proc. Int. Geotech. Symp. on Theory and Practice of Earth
Reinforcement
, October, Fukuoka, Japan, 209–214.
and filling of geocells with granular materials.
Knapton, J. 2008. The structural design of heavy duty pavements for
ports and other industries, Edition 4,
Interpave
, Precast Concrete
Paving and Kerb Association.
Ong, R., Song, W.K., Tran, N.M., Pham, X.T. 2011. Geocell mattress
for heavy duty working platform over soft soil.
Proc. Geotec Hanoi
2011 Conference
, Hanoi, Vietnam.
Ooi, T. A., Tee C. H. & Dobie, M. 2004. Some Malaysian experiences
in the application of geosynthetics in soft ground.
Proc. 15th
Southeast Asian Geotechnical Society Conference
, Bangkok. 486-
492.
Watts, K. and Jenner, C. G. 2008, Large-scale laboratory assessment of
geogrids to reinforce granular working platforms,
Proc. EuroGeo4
,
Scotland, Paper #222.
Webster, S.L. 1992. Geogrid reinforced base course for flexible
pavements for light aircraft: test section construction, behavior
under traffic, laboratory tests and design criteria,
Report Number
DOT/FAA/RD-92/25
, US Army Corps of Engineers.
Figure 11. Construction of MSL with granular materials.
Yong, K. Y., Chan, S. F. & Lee, K. K. 1990. Reinforced soil working
platform for offshore jacket fabrication yard.
Proc. 4th
International Conference on Geotextiles, Geomembranes and
Related Products
, The Hague. 223-226.
