3.3
Deformation of Strips during Shear
The plastic strips used in the composite specimen for the
direct shear tests were assessed for physical deformations such
as dents or rupture at the end of each experiment. The nature of
deformations of the plastic strips was examined with respect to
their location in the shear box. Visual inspections revealed that
most of the elements that deformed were within or close to the
shearing zone. The indentations on some of the strips may have
been caused by soil particles as they pressed in to form surface
attachments with the plastic strips (Figure 5a). This was mainly
due to the particle shape and grading of the sandy soils used in
the study that enhanced the frictional bonding between the soil
and the plastic material. Other strips in the specimens were
stretched and compressed due to the shearing action at or near
the shear plane (Figure 5b). The stretched strips were located
parallel to the shearing direction. This indicated that as the
plastic strips were strained relative to the shearing direction,
they improved the soil tensile strength by enabling transfer of
forces arising from the loading conditions. None of the
reinforcements in the composite were severely indented or
ruptured during the shearing since the tensile strength of the
plastic strips was greater than 15MPa compared to the generated
shear forces in the test specimen under for a maximum applied
normal stress of 100kPa.
The laboratory results presented in the study favourably suggest
the possibility of utilizing plastic material as tensile inclusions
in sandy soil to increase the resistance to shear. As
demonstrated in Chebet et al. 2012, the plastic inclusions can
also improve the load bearing capacity and settlement
characteristics of the sand. Additionally, introduction of
perforations on the plastic material further aids in the interaction
between the soil and plastic thereby boosting the soil’s strength
properties. However, a better understanding of the interaction
mechanism in soils reinforced with the plastic material would
be essential to properly document the engineering behaviour of
the soil-plastic composite.
The influence of the soil physical properties, plastic properties
and scale effects would need to be further investigated through
more comprehensive testing in a wider range of stresses using
larger scale tests to eliminate boundary effects. This could in
turn contribute in the development of design methodologies for
projects that may opt to incorporate this type of reinforcement
material resulting in a reduction in project costs. Furthermore,
successful application in the field could permit a reduction of
plastic waste disposed of to landfills bringing along
environmental benefits as a result of more efficient use of
natural resources and reduction of CO
2
emissions.
5 REFERENCES
Andrady A. L. and Neal M. A. 2009. Applications and societal benefits
of plastics. Philosophical Transactions of the Royal Society, B, 364:
1977 - 1984.
Azapagic A., Emsley A. And Hamerton L. 2003. Polymers, the
Environment and sustainable sevelopment. John Wiley & Sons Ltd.
Barnes D. K. A., Galgani F., Thompson, R. C. And Barlaz M. 2009.
Accumulation and fragmentation of plastic debris in global
environments. Philosophical Transactions of the Royal Society, B,
364: 1985–1998.
Chebet F.C., Kalumba D. and Avutia D. 2012. Investigating the effect
of plastic shopping bag waste material on load bearing capacity of
foundation soils in civil engineering. Proceedings of the 21st
WasteCon Conference and Exhibition, East London, South Africa,
376-383.
Figure 5 a): Dented Strips
b) Stretched and Compressed Strips
Chen X., Xi F., Geng Y. and Fujita T. 2011. The potential
environmental gains from recycling waste plastics: Simulation of
transferring recycling and recovery technologies to Shenyang,
China. Waste Management (31) 168–179.
4 CONCLUSION
A comprehensive laboratory direct shear testing programme
was undertaken on composite specimens of sandy soils mixed
with random inclusions of plastic strips obtained from high
density polyethylene shopping bags. Two locally sourced soils,
Klipheuwel and Cape Flats sands were selected for the research
and the influence of plastic strips on the shear strength
parameters of the sandy soils were studied. The effect of
introducing perforations on the plastic strips was further
examined. Parameters of the plastic strip inclusions such as
length, width, concentration and diameter of perforations were
varied to investigate the effect on the peak friction angle. The
plastic strip lengths used in the study were 15 mm, 30 mm and
45 mm, strip widths 6 mm, 12 mm, 18 mm and perforation
diameters of 1 mm and 2 mm made on the 6mm wide strips.
The strips were added to the soil samples at concentrations of
0.1%, 0.2% and 0.3% by weight.
Consoli N. C., Casagrande M. D. T. and Coop M. R. 2007.
Performance of a fiber reinforced sand at large shear strains,
Geotechnique 57 (9), 751–756.
Falorca I. M. C. F. G. and Pinto M. I. M. 2011. Effect of short,
randomly distributed polypropylene microfibers on shear strength
behaviour of soils. Geosynthetics International 18 (1), 2–11.
Gregory G. H. and Chill D. S. 1998. Stabilization of earth slopes with
fiber reinforcement. Proceedings of the Sixth International
Conference on Geosynthetics, Atlanta, Georgia, USA.
Ibraim E. and Fourmont S. 2006. Behaviour of sand reinforced with
fibres. Geotechnical Symposium on Soil Stress-Strain Behavior:
Measurement, Modeling and Analysis, Roma, 807–818.
Maher M. H. and Ho Y. C. 1994. Mechanical properties of kaolinite
fibre soil composite. ASCE Journal of Geotechnical Engineering
120 (8), 1381–1393.
Miller C.J. and Rifai S. 2004. Fiber reinforcement for waste
containment soil liners. Journal of Environmental Engineering
130(8), 891-895.
Results indicate an improvement in peak friction angle on
addition of the solid strips and perforated strips of varied
lengths and concentrations for the both sands. For the scope of
experiments conducted, maximum values for the peak friction
angles were obtained for strips of length 30 mm, concentration
0.1% and perforation diameter of 2 mm. Addition of
perforations on the strips resulted in a further enhancement of
the friction angle as compared to results obtained using
specimens prepared with solid strips. An increase in the
diameter of perforations resulted in higher values of friction
angle at an average of 2
o
for each mm in perforation diameter.
Nhamo, G. 2008. Regulating Plastics Waste, Stakeholder Engagement
and Sustainability Challenges in South Africa. Springer Science,
Urban Forum 19: 83–101.
Santoni R. L., Tingle J. S. and Webster S. L. 2001. Engineering
Properties of Sand-Fibre Mixtures for Road Construction, Journal
of Geotechnical Engineering, ASCE 127 (3), 258–268.
Thompson, R. C., Moore, C. J., vom Saal, F. S. and Swan, S.H. 2009.
Plastics, the Environment and Human Health: Current Consensus
and Future Trends. Philosophical Transactions of the Royal Society
B, 364: 2153–2166.
Zornberg J. G. 2002. Discrete framework for limit equilibrium analysis
of fiber reinforced soil. Géotechnique 52 (8), 593–604.
