0.1 following centrifuge studies by Julio (2009). No
displacements are expected to accrue due to cycling below this
level; further full-scale specific investigation of this lower
threshold is required.
0.0
0.2
0.4
0.6
0.8
1.0
0.0
0.2
0.4
0.6
0.8
1.0
300
250
200
150
100
50
0.02%D
0.2%D
2%D
Q
cyclic
/Q
T
Cycles, N
Q
mean
/Q
T
0
1
10
100
1000
0
10
20
30
Metastable tests
1mm/10cycles
a (mm)
Cycles, N
S 3.R4.CY6
MS 2.R3.CY2
MS 2.R4.CY2
MS 2.R5.CY2
MS 3.R6.CY6
1mm/100cycles
Data not logged
for first 34 cycles
Stable test
Figure 11. 3D plot for accumulated cyclic displacements equivalent to
0.02%D, 0.2%D and 2%D.
6 ACKNOWLEDGEMENTS
Figure 9. Accumulated cyclic displacements for the stable and meta–
stable loading tests
1
10
-10
0
10
20
30
40
50
100
1mm/100cycles
1mm/10cycles
a (mm)
Cycles, N
US 3.R2.CY2
US 2.R3.CY3
US 2.C1.CY3
US 2.R4.CY4
US 2.R5.CY3
US 2.C1.CY4
US 2.R6.CY2
US 2.R6.CY4
US 2.C1.CY5
The above research was funded by the EU (through the GOPAL
project) and Health and Safety Executive (HSE) of UK. We
gratefully acknowledge the Port Autonome de Dunkerque for
providing the test site. The field testing was conducted in
conjunction with Precision Monitoring Control Ltd. of Teesside
UK. The first author has been supported by the Commonwealth
Scholarship Commission during the writing of this paper.
7 REFERENCES
Chow F.C. 1997.
Investigations into displacement pile behaviour for
offshore foundations,
PhD thesis, University of London (Imperial
College).
Jardine R.J. & Standing J.R. 2000.
Pile load testing performed for HSE
cyclic loading study at Dunkirk, France.
Two volumes. Offshore
Technology Report OTO2000 007; Health and Safety Executive,
London. 60p and 200p.
Jardine, R.J., Standing, J.R., & Chow, F.C. 2006. Some observations of
the effects of time on the capacity of piles driven in sand.
Géotechnique
56(4): 227-244.
Figure 10. Permanent accumulated cyclic displacements response for
the unstable tests
Jardine R.J. & Standing J.R. 2012. Field axial cyclic loading
experiments on piles driven sand.
Soils and foundations
52(4): 723
- 736.
Jardine R.J., Puech A. & Andersen K. H. 2012. Cyclic loading of
offshore piles: Potential effects and practical design.
Proceedings of
the SUT 7th International Conference on Offshore Site
Investigation and Geotechnics
, London, UK, pp. 59 - 97.
5 SUMMARY AND CONCLUSIONS
The analysis presented of the axial cyclic loading load–
displacement, stiffness and accumulated displacements
responses seen in tests on steel open-ended pipe piles driven in
silica sand indicate the following.
Julio R.M.H. 2009.
Comportement des pieux et des groupes de pieux
sous chargement latéral cyclique.
These de doctorat, Ecole
Nationale des Ponts et Chaussees, Paris, France.
(1) Axial load–displacement behaviour is highly non-linear,
even at relatively low levels of loading.
(2) The piles’ cyclic stiffnesses generally remained within 20%
of those observed under initial static loading until cyclic failure
was approached.
Karlsrud K., Nadim F. & Haugen T. 1986. Piles in clay under cyclic
axial loading field test and computational modelling.
Proceedings
of the 3rd International Conference on Numerical Methods in
Offshore Piling
, Nantes, France, pp. 165 – 190.
Leblanc C., Houlsby G.T., & Bryne B.W. 2010. Response of stiff piles
in sand to long-term cyclic lateral loading.
Géotechnique
60(2): 79-
90.
(3) The patterns of accumulated displacements depended on
both the mean and cyclic normalised loading levels.
(4) While displacements accumulate rapidly over just a few
cycles in the unstable zone, extended cycling in the stable zone
led to minimal (and stabilising) accumulated displacements and
axial capacity gains (Jardine et al (2006) meta–stable tests
showed intermediate behaviour.
Merritt A.S., Schroeder F.C., Jardine R.J., Stuyts B., Cathie D. &
Cleverly D. 2012. Development of pile design methodology for an
offshore wind farm in the North Sea.
Proceedings of the SUT 7th
International Conference on Offshore Site Investigation and
Geotechnics,
London, UK, pp. 439 - 447.
Parker E. J., Jardine R.J., Standing J.R. & Xavier J. 1999. Jet grouting
to improve offshore pile capacity.
Offshore Technology
Conference, Houston, OTC 10828
1: 415 – 420.
Poulos H.G. 1988. Cyclic stability diagram for axially loaded piles.
Journal of Geotechnical and Geoenvironmental Engineering,
114(8): 877-895.
Rimoy S., Jardine R., and Standing J. 2013. Displacement response to
axial cycling of piles driven in sand.
Geotechnical Engineering
.
165 (GE1): 1 – 16.
