Actes du colloque - Volume 4 - page 536

3194
Proceedings of the 18
th
International Conference on Soil Mechanics and Geotechnical Engineering, Paris 2013
Proceedings of the 18
th
International Conference on Soil Mechanics and Geotechnical Engineering, Paris 2013
4
5 CONCLUSION
The sorption isotherms of Mg
2+
and Cl
-
on the treated and
untreated kaolin and on the treated and untreated dredged
sediment were analyzed. The adsorbed mass of ions was plotted
vs. the equilibrium concentrations. Batch sorption test results
demonstrated that the sorbed mass of magnesium cations was
higher onto the polymer treated soils compared to the untreated
soils. These results are promising in view of metals retention in
polymer treated dredged sediments. To further demonstrate the
higher retention ability of polymer treated clays, the adsorption
of heavy metals on kaolin, bentonite and dredged sediments is
currently under investigation.
Hydraulic conductivity test results of treated and untreated
soils were shown. The hydraulic conductivity to seawater of the
kaolin treated with 8% of the polymer was lower compared to
that of the kaolin treated with 2% of the polymer. This result
demonstrates that the hydraulic performance of a kaolin clay
increases (the hydraulic conductivity decreases) with increasing
polymer dosage. The hydraulic conductivity to seawater of the
dredged sediment treated with 8% of the polymer was
significantly lower compared to that of the untreated dredged
sediment. These results suggest the possible reuse of dredged
sediments as alternative low cost impermeable barrier materials
to isolate polluted sites and landfills.
6 ACKNOWLEDGEMENTS
The authors would like to acknowledge former thesis students
(S. Lerno and R. Van den Steen) and technical staff (J. Van der
Perre) for helping with the experiments.
7 REFERENCES
Bradl, H. 2005
Heavy Metals in the Environment: Origin, Interaction
and Remediation
. University of Applied Sciences, Neubrucke,
Germany
Daniel, D.E, 1993.
Geotechnical Practice for Waste Disposal
. Chapman
& Hall Ed.
Di Emidio, G., Van Impe, W.F., Van Impe, P. (2006).
Geoenvironmental characterization of dredged sediment as
alternative materials for covers.
5
th
ICEG, International Conference
on Environmental Geotechnics
, 2006. Cardiff, UK
Di Emidio, G. 2010.
Hydraulic and chemico-osmotic performance of
polymer treated clays
. PhD dissertation, Ghent University,
Belgium.
Di Emidio, G. 2012.
Clayey barriers
. WO2012/025564 A1.
PCT/EP2011/064542.
Kison, P., Malengier, B., Di Emidio, G., Peiffer, H., Van Keer, R. 2012.
Inverse determination of soil characteristics with a bench-scale
centrifuge.
Inverse Problems in Science and Engineering
.
Gao, Y.Z., He, J.Z., Ling, W.T., Hu H.Q., Liu, F. 2003. Effects of
organic acids on copper and cadmium desorption from
contaminated soils
. Environment International
29, 613-618.
Garcia-Sanchez, A., Alastuey, A., Querol, X. 1999. Heavy metal
adsorption by different minerals: application to the remediation of
polluted soils.
The Science of the Total Environment
242, 179-188.
Griffin, R.A., Shimp, N.F., Steele, J.D., Ruch, R.R., White, W.A.,
Hughes, G.M. 1976. Attenuation of pollutants in municipal leachate
by passage through clay.
Environmental Science and Technology
10, 1262-1268.
Ling, W., Shen, Q., Gao, Y., Gu, X., Yang, Z. 2007. Use of bentonite to
control the release of copper from contaminated soils.
Australian
Journal of Soil Research
, 2007, 45, 618-623.
Malusis, M, Benson, C. 2006. Lysimeters versus water-content sensors
for performance monitoring of alternative earthen final covers.
Geotechnical Special Publication, 147, 741-752, 2006,
Proceedings
of the Fourth International Conference on Unsaturated Soils
Mazzieri, F., Pasqualini, E;, Di Emidio, G; 2010. Migration of Heavy
Metals Through Conventional and Factory-Prehydrated GCL
Materials.
Proceedings of the 6xth ICEG, International Conference
on Environmental Geotechnics
, 2010. Delhi, India
Meegoda, J.N., Ruvini, P. 2001. Ultrasound to decontaminate heavy
metals in dredged sediments.
Journal of Hazardous Materials
, 85,
73-89.
Mitchell, J. 1993.
Fundamentals of soil behaviour
, John Wiley & Sons.
Mulligan, C.N., Yong, R.N., Gibbs, B.F. 2001. An evaluation of
technologies for the heavy metal remediation of dredged sediments.
Journal of Hazardous Material
85, 145-163.
Rajasekaran, G., Kamon, M., Katsumi, T., Inazumi, S. 2000. Evaluation
of waste sludge as landfill cover.
Annuals of Disas. Prev. Res. Inst.,
Kyoto University
, No. 43 B-2, 2000
Peng, J., Song, Y., Yuan, P., Cui, X., Qiu, G. 2009. The remediation of
heavy metals contaminated sediment.
Journal of Hazardous
Materials
, 161, 633-640.
Plassard, F., Winiarski, T., Petit-Ramel, M. 2000. Retention and
distribution of three heavy metals in a carbonated soil: comparison
between batch and unsaturated column studies.
Journal of
Contaminant Hydrology
42, 99-111.
Shackelford, C.D. 2005. Environmental issues in geotechnical
engineering. Keynote Lecture.
Proceedings of the 16th
International Conference on Soil Mechanics and Geotechnical
Engineering
. Osaka, Japan.
Sharma, H.D. and Reddy, K.R. 2004.
Geoenvironmental Engineering.
John Wiley & Sons, Hoboken, New Jersey.
Singh, S.P., Ma, L. Q., Tack F.M.G., Verloo, M.G. 2000. Trace Metal
Leachability of Land-Disposed Dredged Sediments.
Journal of
Environmental Quality
29 (4), 1124-1132.
Zornberg, J.S., McCartney, J.G. 2010. Centrifuge Permeameter for
Unsaturated Soils I: Theoretical Basis and Experimental
Developments
Journal of Geotechnical and Geoenvironmental
Engineering
, Vol. 136, No. 8, August 1, 2010.
