For the HDPE geomembranes δ
max
was rather
insensitive to the variation of degree of saturation. The
mobilized tensile force in the geomembrane was also insensitive
to the variation of soil degree of saturation, with some higher
values for some tests, but without allowing a conclusion on the
influence of moisture content on the value obtained (probably a
result of test scatter).
The highest values of F were obtained in the tests with
the texturized HDPE geomembrane, whereas the lowest ones
were obtained in the tests with the smooth PVC geomembrane.
The smallest values of δ
max
were also obtained in the tests with
the smooth PVC geomembrane.
4 CONCLUSIONS
This paper presented results of ramp and direct shear
tests on different geomembrane products in contact with a sandy
soil. The degree of saturation of the soil was varied during the
test to assess possible influence of this parameter on the
adherence between soil and geomembrane. The results obtained
showed that the interface friction angle between soil and
geomembranes was insensitive to the variation of soil degree of
saturation for the conditions employed in the test programme.
A progressive interface failure mechanism was observed in the
tests with PVC geomembranes due to the more extensible
nature of this type of geomembrane.
The largest values of interface friction angles were
obtained in the tests with the texturized HDPE geomembrane,
whereas similar lower values were obtained in the tests with the
smooth PVC and HDPE geomembranes. As a consequence of
higher adherence with soil, the largest mobilized tensile forces
were obtained in the tests with the texturized HDPE
geomembrane.
5 ACKNOWLEDGEMENTS
Authors would like to thanks Maccaferri, Sansuy e
Nortene Geosynthetics Ltd. for having supplied the
geomembrane products tested. The authors are also indebted to
the University of Brasilia, CAPES-Brazilian Ministry of
Education and CNPq-National Council for Scientific and
Technological Development for the financial support.
6 REFERENCES
Arya, L. M., Paris, J. F. 1981. A physico-empirical model to predict the
soil moisture characteristic from particle-size distribution and bulk
density data. Soil Science Society of America Journal, 45: 1023-
1030.
Aguiar, V. R. de. (2003). Ramp tests for soil-geosynthetic shear strength
interface studies. MSc Dissertation, Graduate Program on Civil
Engineering, Federal University of Rio Grande of Sul, Porto
Alegre, RS, Brazil, 121p (in Portuguese).
Briançon, L.; Girard, H.; Poulain, D. (2002). Slope stability of lining
systems-experimental modeling of frictional at geosynthetic
interfaces. Geotextiles and Geomembranes, 13 (5): 147-172.
Dwyer, S.F.; Bonaparte, R.; Daniel, D.E.; Koerner, R.M.; Gross, B.
(2002). Technical guidance for RCRA/CERCLA final covers. US
Environmental Protection Agency, Office of Solid Waste and
Emergency Response, Washington, DC, USA.
Fleming, I. R.; Sharma, J. S.; Jogi, M. B. (2006). Shear strength of
geomembrane-soil interface under unsaturated conditions (in
English). Geotextiles and Geomembranes, (24): 274 - 284.
GEO-SLOPE International Ltda. (2004). GeoStudio Tutorials (includes
student edition lessons). Calgary, Alberta, Canada.
Girard, H.; Fisher, S.; Alonso, E. (1990). Problems of friction posed by
the use of geomembranes on dam slopes-examples and
measurements. Geotextiles and Geomembranes 9 (2), 129-143.
Giroud, J.P.; Swan, R.H.; Richer, P.J.; Spooner, P.R. (1990).
Geosynthetic landfill cap: laboratory and field tests, design and
construction. 4
th
International Conference on Geotextiles,
Geomembranes and Related Products, The Hague, The
Netherlands, Vol. 2, 493-498.
Girard, H.; berroir, gourc, J. P.; matheus, G. (1994). Friction behavior of
geosynthetics and slopes stability of lining systems (in English).
Fifth International Conference on Geotextiles, Geomembranes and
Related Products, Singapore, (1): 339 - 342.
Gourc, J.P.; Lalarakotoson, S.; Müller-Rochholtz; H., Bronstein, Z.,
(1996). Friction measurements by direct shearing or tilting process
– development of a European standard. 1
st
European Conference on
Geosynthetics - EUROGEO 1, Maastricht, The Netherlands, Vol. 1,
1039-1046.
Gross, B.A.; Bonaparte, R.; Giroud, J.P. (2002). Waste containment
systems: problems and lessons learned. Appendix F, Assessment
and Recommendations for Optimal Performance of Waste
Containment Systems, EPA, USA, 214 p.
International Organization for Standardization. (2005). ISO 12957-2:
Geosynthetics - Determination of friction characteristics - Part 2:
Inclined plane test. 10p.
Khoury, C. N.; Miller, G. A.; Hatami, K. (2011).Unsaturated soil –
geotextile soil interface behavior. Geotextiles and Geomembranes,
(29): 17 - 28.
Izgin, M. & Wasti, Y. (1998). Geomembrane – sand interface frictional
proprieties as determined by inclined board and shear box tests (in
English). Geotextiles and Geomembranes, 16 (4): 207 – 219.
Koutsourais, M.; Sandri, D.; Swan, R. (1998). Soil Interaction
characteristics of geotextiles and geogrids (in English). Sixth
International Conference on Geosynthetics, pp. 739 – 743.
Lima Júnior, N. R. (2000). Soil-geosynthetic interaction study for
environmental protection constructions using ramp test equipment.
MSc Dissertation, Publication G.DM – 071A/2000, Department of
Civil and Environmental Engineering, University of Brasília,
Brasília,DF, Brazil, 48 p (In portuguese).
Lopes, C. P. F.C. (2001). Study of soil and geosynthetic interaction by
shear tests and inclined board tests. MSc Dissertation, Civil
Engineering University, Porto City, Portugal, 186p (in Portuguese).
Mello, L. G. R. de (2001). Soil-geosynthetic interaction study for waste
landfills slopes. MSc Dissertation, Publication G.DM – 085A/01,
Department of Civil and Environmental Engineering, University of
Brasilia, Brasília, DF, Brazil, 137 p (In portuguese).
Palmeira, E.M. (2009). Soil-geosynthetic interaction: Modelling and
analysis. Geotextiles and Geomembranes 27: 368-390.
Rebelo, K. M. W. (2003). Soil-geomembrane interface strength by Righ
Shear tests. MSc Dissertation, Graduate Program on Civil
Engineering, Federal University of São Paulo, São Carlos, SP,
Brazil, 216p (in Portuguese).
Viana, H. N. L. (2007). Study of stability and permeability of
conventional and alternative covering systems for waste landifills.
DSc Thesis, Publication G.TD – 048/07, Department of Civil and
Enrironmental Engineering, University of Brasília, Brasília, DF,
Brazil, 259p (In portuguese).
