cohesion
”
as geocell and sand are integrated as a composite
material. In addition, the deformed geocell inducing a large
passive earth pressure in the soil within cell pockets would
prevent the development of tension cracks close to the footing,
which was observed in the natural ground without the geocell
reinforcement.
50
40
30
20
10
0
-10
0
100
200
300
400
Natural ground without reinforcement
Geocell-reinforced ground
Distance from footing, d/B (%)
Surface settlement, h/B (%)
Figure 9. Ground surface settlement profile (negative values implying
ground heave).
Figure 10. Soil deformation suggested with the PIV technique:
(a) three-layer geocell-reinforced ground; (b) natural ground
without reinforcement.
5 REFERENCES
Das B. M., 1999. Principles of Foundation Engineering 4
th
ed. PWS
Publishing.
Dash, S.K., Krishnaswamy, N.R. and Rajapopal, K. 2001. Bearing
capacity of strip footings supported on geocell-reinforced sand.
Geotectiles and Geomembranes
19(4): 235-256.
Krishnaswamy N.R., Rajagopal K. and Madhavi Latha G. 2000. Model
studies on geocell supported embankments constructed over a soft
clay foundation.
Geotechnical Testing Journal
, 23(1), 45-54.
Leshchinsky B. and Ling H.I. (2012). Effects of geocell confinement on
strength and deformation behavior of ballast.
Journal of
Geotechnical and Geoenvironmental Engineering
,
ASCE.
(accepted)
Leshchinsky D., Ling H.I., Wang J.P., Rosen A. and Mohri Y.
2009. Equivalent seismic coefficient on geocell retention
systems.
Geotextiles and Geomembranes
27, 9-18
Ling, H.I., Leshchinsky, D., Wang, J-P., and Rosen, A. 2009. Seismic
response of geocell retaining walls: Experimental studies."
Journal
of Geotechnical and Geoenvironmental Engineering
, ASCE,
135(4), 515-524.
Rajagopal K., Krishnaswamy N.R. and Madhavi Latha G. 1999.
Behaviour of sand confined with single and multiple geocells.
Geotectiles and Geomembranes
17, 171-184.
Tafreshi S.N.M. and Dawson A.R. 2010. Comparison of bearing
capacity of a strip footing on sand with geocell and with planar
forms of geotextile reinforcement.
Geotectiles and Geomembranes
28(1), 72-84.
Tsou C.Y., Feng Z.Y. and Chigira M. 2010. Catastrophic landslide
induced by Typhoon Morakot, Shiaolin, Taiwan.
Geomorphology
127, 166-178.
Wang J.P. 2007. Full-scale shaking table tests of reinforced retaining
walls with geocell facing (Ph.D Thesis). Columbia University, New
York City
Wesseloo J., Visser A.T. and Rust E. 2008. The stress-strain behavior of
multiple cell geocell packs.
Geotectiles and Geomembranes
27, 31-
38.
White D.J., Take W.A. and Bolton M.D. 2003. Soil deformation
measurement using particle image velocimetry (PIV) and
photogrammetry.
Géotechnique
53(7), 619-631.
Wu K.J. and Austion D.N. 1992. Three-dimensional polyethylene
geocells for erosion control and channel linings.
Geotectiles and
Geomembranes
11(4-6), 611-620.
(a)
(b)
