          (e.g., Dyvik and Olsen (1991), Zeng and Ni (1998), Lee and


          Santamarina (2005), Lee et al. (2007)). The bender element tip-


          to-tip separation is 6.2 cm, yielding a ratio of test specimen


          diameter to sensor separation of approximately 2.45. The


          sample height is 15.8 cm. Figure 2 contains a view of the test


          system including key ancillary equipment.


          Glass beads used for the granular testing matrix are 0.5 mm


          in diameter. Consideration is given to optimize uniformity and


          repeatability of the placement of the glass beads, in order to


          minimize unwanted acoustic impedance contrasts in the


          medium, to discourage preferential fluid flow pathways, and to


          facilitate comparisons among tests.  The oven-dried glass beads


          are vibrated into place using a vibratory table operating at 60 Hz


          for 20 minutes with a surcharge load of 28 kg. The surcharge


          mass was selected based on the methodology laid out by ASTM


          D4253 - 00(2006) Standard Test Methods for Maximum Index


          Density and Unit Weight of Soils Using a Vibratory Table. The


          surcharge mass is kept in place throughout testing. It


          approximates a vertical overburden stress of 15 kPa.


          The glass beads are flooded with de-ionized (DI) water


          which is introduced through upward flow distributed across the


          cross-section of the experimental column.  The water is plumed


          into the bottom of the test chamber to reduce the amount of


          entrapped air and is plumed under gravity flow with total head


          not exceeding 0.3 meters. The fluid-flow gradient is kept low to


          discourage entrainment of air bubbles and approximate laminar


          flow. The fluid passes through a set of baffles and a perforated


          disc before entering the sample (Figure 1). This process is


          intended to encourage a uniform wetting front and discourage


          fingering and the formation of preferential flow pathways. A


          somewhat loose-fitting top cap allows the cell to be completely


          flooded


          and allows the overburden stress to act directly on the


          specimen


          .  Excess water exits the test apparatus through a port


          above the cap. Satisfactory dispersion of liquid through the


          glass-bead-filled test chamber was demonstrated using colored


          dye (Figure 3). The capacity of the fluid-delivery system


          including test cell is approximately 1.7 liters.


          Data are collected with a Data Physics (Data Physics, Inc.)


          dynamic signal analyzer.  Single sine pulses are created using a


          function generator. The sampling interval is 9.301


          microseconds. The signal is not filtered during data capture.


          The reported result is an average from 350 pulses, which are


          repeated at 0.7-second intervals.


          3 BASELINE TESTING


          Through resonance testing and experimental trials, optimum


          frequencies to test for shear and compression were determined


          to be 1 kHz and 8 kHz, respectively. The compression


          measurements have not yet been resolved satisfactorily because


          of complications with electrical crosstalk between source and


          receiver and are not presented here. Results of baseline testing


          for shear (using DI water, with no experimental treatment) are


          shown in Figure 4. Four datasets are collected. The first dataset


          is collected after initial inundation of the sample. Repeat


          collections occur after 4, 8 and 12 additional liters of DI water


          are flushed through the sample. The time history from the initial


          measurement is dramatically different from those collected


          later. Results demonstrate that up to four liters of fluid need to


          be flushed through the system before the response stabilizes.


          The flushing process is likely to improve the signal by expelling


          entrained air.


          The zero time in Figure 4 corresponds to source initiation.


          Based on first arrival by visual interpretation, the shear wave


          velocity of the specimen is approximately 170 m/s.


          Considering the timing for the first troughs in the signals,


          velocity estimates among the three measurements (after flushing


          4, 8 and 12 liters of DI water) would vary by approximately +/-


          3 %. Amplitudes at the first trough vary by +/- 17%.


          4 NANOPARTICLE EFFECTS


          The test sequence was repeated on a new sample, in which a


          solution of 0.05% (by weight) nZnO solution was introduced.


          The nanoparticle treatment solution is made through sonication


          to uniformly disperse the nanoparticles in DI water.  Eight liters


          of clean DI water were flushed through the test chamber first,


          followed by 4 liters of the nanoparticle solution.


          Results are shown in Figure 5. Again, the dataset conducted


          before flushing was not representative of results after flushing.


          The time histories collected after flushing but before


          introducing the nZnO treatment would ideally be the same as


          those collected in the baseline test.  However, comparison with


          Fig. 4 demonstrates that the tests are not closely repeatable


          between samples, despite careful efforts to replicate test


          conditions.  For example, consider the difference in signal


          amplitude between the two figures. This is an unfortunate


          discrepancy that requires further investigation. From Figure 5,


          considering the time histories gathered after flushing 4 and 8


          liters of DI water, the shear wave velocity is approximately 150


          m/s, which represents a decrease of 12 % with respect to


          baseline (Figure 4). Also, for the later test (Figure 5), results do


          not stabilize as fluid flushing occurs to the extent seen in


          baseline testing. Repeating analyses of the timing and amplitude


          of the first trough, velocity estimates among the measurements


          after flushing 4 and 8 liters would vary by approximately +/- 9


          % and amplitudes by +/- 3 %. With respect to the baseline test,


          the percentage variabilities are higher for velocity and lower for


          amplitude.


          Despite the variability observed with DI water, the trial


          conducted after introducing the nZnO experimental treatment


          (labeled in Figure 5 as “12”) shows distinctly different results


          from those collected earlier on the same test specimen. Signal


          amplitude is dramatically increased, and timing is delayed. To


          effectively quantify differences, cross-correlation of traces,


          signal matching or coda wave analysis might be applied (Lee


          and Santamarina 2005, Dai et al. 2012).


          The significant increase in signal amplitude might be due to


          agglomeration of nZnO onto the glass bead matrix (Klaine et.


          al., 2008) which would enhance contacts in the skeletal


          structure of the glass bead matrix, thereby reducing signal


          attenuation.  The smaller decrease in velocity is not as readily


          explained. One hypothesis (which is yet untested) is that the


          flushing process allows sufficient displacement of the glass


          beads to permit introduction of nanoparticles between contacts.


          This possibility seems unlikely given the slow influent flow rate


          and the amplitude of the surcharge pressure.


          5 CONCLUSIONS


          A laboratory apparatus has been developed to study seismic


          response to the presence of nanoparticles dispersed in the pore


          fluid of saturated granular media. Uniform placement of the


          solid sample matrix is encouraged through the use of a vibratory


          table and a surcharge load.  A perforated plate and baffle system


          for introduction of fluid at the bottom of the test cell encourage


          laminar flow and uniform fluid distribution which is


          demonstrated using dye. Baseline testing in clean water using


          sine pulses at 1 kHz, chosen to optimize transmission of shear


          energy, demonstrated that by first flushing several liters of fluid


          through the sample, repeated measurements would yield similar


          results.  Testing a new sample demonstrated that close


          repeatability of results is not assured between samples.


          The measurements revealed sensitivity of the nanoparticle


          treatment to shear wave energy propagation. After flushing a


          sample with a treatment containing 0.05% nZnO, measurements


          revealed a dramatic increase in signal amplitude and a slight


          increase in travel time. Changes might be due to agglomeration


          of nanoparticles on the granular matrix which enhances grain-


          to-grain contacts, possibly coupled with insertion of


          nanoparticles between grains which reduce system stiffness.


          Further experimentation is required to assess if the observed


          responses are indeed trends. Once accomplished, the research


          will expand to increase experimental sensitivity and broaden


          scope, and to more closely approximate conditions in nature.
