-200 0 200 400 600 800 1000 1200 1400 1600
0,0
0,2
0,4
0,6
0,8
1,0
U U
carillo
(400 kPa)
time (min)
Degree of consolidation
(a)
(b)
figure 4. Variation of global degree of consolidation
for applied loads (100, 200, 400 and 800 kpa), it is
noted that the degree of consolidation as predicted by
the Carillo’s theory
reaches 100% for a time less than 24
hours, while the degree of consolidation U, estimated
from equation (11) by using measurements of serie 3
results, reaches 100% in 24 hours.
one can also remarks
that by using the Carillo’s theory
a
lower degree of consolidation which starts from 10% is
obtained, however when using measurements of in series
3 simple approximate methods, higher degrees of
consolidation starting from 70% are obtained.
comparing between recorded and predicted global
degree of consolidation U, it follows that the evolution
of U predicted by the
Carrillo’s theory are overestimated
with respect to that deduced from recorded settlement
from series 3. the final global consolidation degree U is
identical by using the two methods.
conclUsion
this paper presented an experimental study conducted
on tunis soft clay, in which three types of oedometer
tests were executed: a standard oedometer test; an
oedometer test on specimen soil improved by an element
of geodrain and test a similar test to the second one by
preventing the vertical drainage. from measurements
coefficients of permeability k
v
and k
r
were determined
by the variable head permeability test. in addition,
coefficients of vertical and radial consolidation c
v
and
c
r
were determined from the evolution in time of
settlement at different levels of consolidation stress.
comparison between the ratios k
r/
k
v
and c
r/
c
v
demonstrated that equality between the two ratios only
happens at high level of stress consolidation, contrarily
to the common assumption made in previous studies.
predictions of the global degree of consolidation showed
that
the Carillo’s theory
leads to overestimated results
with respect to predictions from recorded settlements.
further, the effect of vertical and radial consolidations
from the observed global consolidation of improved
tunis soft soils was discussed.
Acknowledgement:
authors gratefully appreciate the help provided by mrs.
s. Boussetta during the experimental work carried out at
the soil mechanics laboratory of the national
engineering school of tunis.
References
Barron a., (1948). «consolidation of fine grained soils
by drains wells», american society of civil engineers,
Journal of soil mechanics, Volume 73, pp 718-743.
carillo n., (1942). «simple two-and three-dimensional
cases in the theory of consolidation of soils», Journal of
mathematics and physics, Volume, n°1, pp 1-5.
casagrande a. (1938) notes on soil mechanics-first
semester. harvard University 1-29.
Guofu.Z and Jian-
Hua, (2001). “Design charts for
vertical drains considering construction time”. Canadian
Geotechnical Journal. 38: 1142
–
1148.
hansbo, s. (1981). consolidation of fine-grained soils
by prefabricated drains. proceedings of 10th
international conference on soil mechanics and
foundation
engineering,
stockholm,
Balkema,
rotterdam, 3, pp. 677-682.
indraratna. B, and rujikiatkamjorn .c. (2006)
“Predictions and Performance
s of prefabricated Vertical
drain stabilized
Soft Clay Foundations”.
proceedings
of the symposium on rigid inclusions in difficult soft
soil conditions international society for soil mechanics
and Geotechnical engineering (issmGe tc36).
Jia, r. and chai, J. c. (2010). effect of strain
distribution pattern on interpreting crs consolidation
test results. proceedings of the fourth Japan-china
Geotechnical symposium, okinawa, Japan, 29-36.
Kjellman W. (1948). accelerating construction of fine-
grained soils by means of card board wicks. in
proceedings of the 2nd international conference on soil
mechanics and foundation engineering,rotterdam. Vol.
2, pp. 302
–
305.
Kjellman W. (1948). Discussion: “Consolidation of fine
-
grained soils by drain wells” by R.A. Barron.
transactions, asce,113 (2346): 748
–
751.
parakash ,.K, sridharan . a and asha, sr (1996).
consolidation behavior of clayey soils under radial
drainage. Geotech.test. J, astm, 19 (4), 421-431.
sridhar, G and robinson,
G (2011) “
determination of
radial coefficient
of consolidation using log t method”.
international Journal of Geotechnical engineering (373-
381).
terzaghi, K. 1943. theoretical soil mechanics. Wiley,
new York.
tyn myint-U. 1980. partial differential equations of
mathematical physics. elsevier, north holland.
-200 0 200 400 600 800 1000 1200 1400 1600
0,0
0,2
0,4
0,6
0,8
1,0
U U
Carillo
(800 kPa)
time (min)
Degree of consolidation
